Hi everyone!  Wow – yesterday was a big day, with a lot of amazing announcements at PDC ‘09 – especially the announcement that the Silverlight 4 Beta was publicly available.  I was very excited to be given an opportunity to give a talk at PDC this year, and it was a real treat.  My talk – Building Line of Business Applications with Silverlight 4 (PDC09-CL19) – focused on the new features in Silverlight 4 that are particularly useful in business applications, especially those that are data-centric. (Please ignore the abstract given on that page for the talk – it wasn’t updated properly from a change we made to it early on! :))

After the announcement of Silverlight 4, my talk appeared on the big board!

The talk covered a wide array of features, but I broke things down into three conceptual categories around data:

  • Data Interactivity (i.e. how do I drill down into my data to find what I’m looking for?)
  • Data Entry (i.e. how do users add/edit data and what kind of feedback do you give them to minimize mistakes?)
  • Data Presentation (i.e. how do I communicate data to a user, but also how do I communicate intent for data entry, such as “choose from this list of options” to a user?)

The Silverlight 4 features I covered generally fit into these categories:

  • Data Interactivity
    • Data sources window (VS2010)
    • Selector support (i.e. SelectedValue/SelectedValuePath on ComboBox and related controls)
    • Binding TargetNullValue
    • Binding FallbackValue
    • ICommand support on ButtonBase (i.e. Command and CommandParameter) and Hyperlink
  • Data Entry
    • Asynchronous validation
    • Cross-field validation
  • Data Presentation
    • Binding StringFormat
    • CollectionViewSource Grouping
    • Printing and pagination
    • DataGrid * Columns (*-based column sizing, as with the Grid control)

And all of this is just the short list of features I could cover in my 50-minute talk!  There are certainly other business application-friendly features out there, but more importantly, the feature list for Silverlight 4 is just huge!  The talk also used Visual Studio 2010 Beta 2, which provides an awesome development environment for Silverlight.

I won’t go into too much detail here, but I wanted to share out my powerpoint deck and sample/demo code so that those who were in attendance at the talk can look back for reference, and those that weren’t can see what they were missing.  I don’t know for sure yet, but I think there will be a webcast of the talk online at some point, and I’ll be happy to link to that once it’s available.

So, without further ado, here are the links:

Before I leave you, I’d like to just give a brief overview of the sample application.  The application itself is an issue tracker – allowing you to file bugs/issues, assign them to people, resolve the bugs, etc.  It has 4 functional pages:

  • New Issue
    • Allows users to file a new bug/issue
  • All Issues
    • Allows users to see a list of all bugs in the database
  • My Issues
    • Allows users to see un-fixed issues that are assigned to them
  • Reports
    • Allows users to see a report of all of the issues in the database and print them if he/she so desires

The application was built using LINQ-to-SQL and WCF RIA Services (formerly .NET RIA Services), which made getting off the ground with real data running on a real database extremely quick and easy.  If you’re still around at PDC, there are a few talks later today on RIA Services by Brad Abrams and Dinesh Kulkarni you should check out.

A few things to try in the application (some of which I didn’t go over in the talk):

  • Right-click and change the theme of the application
    • Many thanks to my co-worker Jesse Bishop for his ContextMenu control
    • This feature uses implicit styles (new in SL4) to change the entire look of the application
  • Set the priority on a bug to be lower than (i.e. a larger number than) severity and see the validation UI (cross-field validation)
  • Set the title of an issue to be something wholly contained in another issue’s title to see the validation UI (asynchronously querying the server for “similar” bugs)
  • Drag and drop a file from your disk into the list of files on a bug (one of the tabs at the bottom)
  • Print out a set of reports on the reports page (click the “Print” button)
  • Set a value in the “Tags” field and then change it in the DataGrid under the Attributes tab on a bug, noticing that they stay in sync (thanks to bindings to string indexers)
  • Use the mouse-wheel almost anywhere and note that it works without any code to make it happen!
  • Explore the code!  I know there are some bugs in the application and in our beta product, but the hope is to give you an idea of how you can use these features in a business application.  I’m sure there will be lots of content out there about all of these features – but this should help introduce you to them!

Well, thanks again everyone who was able to join me for my talk, and to all those who’ve been following me on twitter through this exciting announcement.  Let me know if you have questions or if there’s anything you’d like me to expand on, and I’ll be more than happy to chime in!



Links to materials repeated here for convenience:

Update (11/19/2009): Video of the talk is now available here: http://microsoftpdc.com/Sessions/CL19

Update (11/20/2009): Video of the talk is embedded below:

Get Microsoft Silverlight

P.S.  Sorry for the lack of posts recently – I’ve got a bunch of new topics lined up, but it was a pity not to be able to write about Silverlight 4 before it was announced.  Expect another series on Navigation coming soon!



Update (12/21/2009): I think I’ve figured out the issue people were having with the downloaded project.

If you’re receiving an error like this when you try to build my project:

Error 4 The "ValidateXaml" task failed unexpectedly.

This is happening because Windows protects you from downloaded files by default (VS2010 will warn you when you open the project that they come from “untrusted sources.”  Fixing this is pretty straightforward.

  1. Download the zip.
  2. Right-click the downloaded zip file and choose “Properties”
  3. At the bottom of the “General” tab, there is a “Security” section, saying “This file came from another computer and might be blocked to help protect this computer.”  Click the “Unblock” button.
    Click the "Unblock" button.
  4. Unzip and open the solution.
  5. Build and run!

Sorry it took me so long to figure this one out!  It had me stumped for a while.
